DTX Series Long Range Radio Alarm Transceivers
DTX Series Long Range Radio Alarm Transceivers
The DTX Series are versatile and cost-effective Alarm Reporting/Command & Control Transceivers that can be configured to operate as a one-way radio transmitter or a two-way radio transceiver.
The two-way configuration allows the system to be used for command and control functions that are well suited for industrial, institutional, and military applications. DTX is available with 4 or 16 supervised, dry contact inputs that can be used for zone alarm reporting and/or other status reporting functions.
DTX can also provide 4 relay outputs that can be programmed to operate by that DTX unit, by remote control from a TRX50 System Processor in a two-way system, or by a combination of local and remote control.
Integration with TRX50 for Wide Area Mass Notification
When used with the TRX50 system, the DTX output relays can be used to activate live or prerecorded voice communication to outdoor areas, specific buildings, groups of buildings, or throughout an entire military complex, campus, or industrial/institutional facility.
This integration makes the DTX Series a key field node in SigCom's end-to-end emergency reporting and wide area mass notification platform — extending two-way command and control to virtually any location on the network.
Key Features
- One-way, two-way, and voice configuration options
- 4 or 16 supervised dry contact initiation circuits
- Prioritized alarm and trouble messages
- Transmits 32 different event types
- 4 command/control relays (Form C)
- Serial port option for data communications with intelligent panels and devices
- Mass notification activation via TRX50 integration
- Weatherproof NEMA 3R enclosure
- Remote control from TRX50 System Processor
- Local and remote control combination mode
- Suitable for industrial, institutional, and military use
- Cost-effective alarm reporting and command/control solution
Typical Applications
